Mixer – analogue
Inputs – 4 Channels (2x Mic/Line, 1x Hi-Z, 1x RCA & Bluetooth)
Input connectors – 2x XLR jack combo, 1x UNBAL TRS Jack, 1x RCA stereo
Input impedance – 10 k Ohms Balanced, 470 k Ohms Unbalanced
Output connector – 2x Line link XLR, 1x Main out XLR (pre DSP)

Vertical Array:
MF – 6x 3″ mid-range speaker
HF – 1x 1″ compression driver
Coverage (HxV) – 120° x 30°
Rated Power – 180 W (RMS)
Rated Impedance – 6Ω
Dimensions(WxHxD) – 108 x 835 x 98 mm
Net Weight (kg) – 3.9kg

Subwoofer:
Speaker type – 1 x 10″ transducer
Rated Power – 250W (RMS)
Rated Impedance – 4Ω
Dimensions (WxHxD) – 358 x 616 x 447 mm

Amplifier:
Rated power – 2 x 300 W RMS
Frequency range – 20 Hz – 20 kHz
DSP connection – 24 bit (1in-2out)
